OCEANAIRE OWC Series

Ambient Operating Range 65°-105°F

Cooling Capacity 1 ton 12,000 Btu/h

Voltage/Amps (@60Hz) 115 1-Phase

Amps (A) 8.1

Plug Configuration NEMA 5-15P

Dimensions (W x H x D) 28.5 (w/casters 33.75) x 20.125 x 13.125

Ambient Operating Range 65°-105°F

Cooling Capacity 1.5 ton 18,000 Btu/h

Voltage/Amps (@60Hz) 115 1-Phase

Amps (A) 11.3

Plug Configuration NEMA 5-15P

Dimensions (W x H x D) 34.5 (w/casters 39.75) x 24.25 x 13

Ambient Operating Range 65-105°F

Cooling Capacity 2 ton 23,950 Btu/h

Voltage/Amps (@60Hz) 208-230 1-Phase

Amps (A) 9.9

Plug Configuration NEMA 6-20P

Dimensions (W x H x D) 34.5 (w/casters 39.75) x 24.25 x 13

Ambient Operating Range 65°-105°F

Cooling Capacity 3 ton 36,100 Btu/h

Voltage/Amps (@60Hz) 208-230 1-Phase

Amps (A) 12

Plug Configuration NEMA 6-20P

Dimensions (W x H x D) 45 (w/casters 50.25) x 28.25 x 18

Ambient Operating Range 65°-105°F

Cooling Capacity 3 ton 36,100 Btu/h

Voltage/Amps (@60Hz) 208-230 3-Phase

Amps (A) 9.3

Plug Configuration NEMA L15-20P

Dimensions (W x H x D) 45 (w/casters 50.25) x 28.25 x 18

Ambient Operating Range 65°-105°F

Cooling Capacity 3 ton 36,100 Btu/h

Voltage/Amps (@60Hz) 460 3-Phase

Amps (A) 4.7

Plug Configuration NEMA L16-20P

Dimensions (W x H x D) 45 (w/casters 50.25) x 28.25 x 18

Ambient Operating Range 65°-105°F

Cooling Capacity 5 ton 60,100 Btu/h

Voltage/Amps (@60Hz) 208-230 1-Phase

Amps (A) 23.7

Plug Configuration NEMA 6-30P

Dimensions (W x H x D) 45.25 (w/casters 51.50) x 27 x 29 (w/2in kick plate)

Ambient Operating Range 65°-105°F

Cooling Capacity 5 ton 60,100 Btu/h

Voltage/Amps (@60Hz) 208-230 3-Phase

Amps (A) 16.5

Plug Configuration NEMA L15-30P

Dimensions (W x H x D) 45.25 (w/casters 51.50) x 27 x 29 (w/2" kick plate)

Ambient Operating Range 65°-105°F

Cooling Capacity 5 ton 60,100 Btu/h

Voltage/Amps (@60Hz) 460 3-Phase

Amps (A) 6.3

Plug Configuration NEMA L16-20P

Dimensions (W x H x D) 45.25 (w/casters 51.50) x 27 x 29 (w/2" kick plate)
