OCEANAIRE PAC SERIES
Need help selecting the right OceanAire PAC Series unit? No worries – Spot Coolers can help. Our experts are ready to answer your questions at any time.
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 1 ton 11,800 Btu/h
Voltage/Amps (@60Hz) 115 1-Phase
Amps (A) 10.4
Plug Configuration NEMA 5-15PLCDI
Dimensions (W x H x D) 32.5 (w/casters 37.75) x 20 x 25
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 1.5 ton 16,800 Btu/h
Voltage/Amps (@60Hz) 115 1-Phase
Amps (A) 14.1
Plug Configuration NEMA 5-20P LCDI
Dimensions (W x H x D) 40.5 (w/casters 45.75) x 24 x 30
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 2 ton 24,020 Btu/h
Voltage/Amps (@60Hz) 208-230 1-Phase
Amps (A) 14.9
Plug Configuration NEMA 6-20P LCDI
Dimensions (W x H x D) 40.5 (w/casters 45.75) x 24 x 30
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 3 ton 36,050 Btu/h
Voltage/Amps (@60Hz) 208-230 1-Phase
Amps (A) 18.1
Plug Configuration NEMA 6-30P LCDI
Dimensions (W x H x D) 45 (w/casters 50.25) x 27.5 x 35 (w/2in kick plate)
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 3 ton 36,050 Btu/h
Voltage/Amps (@60Hz) 208-230 3-Phase
Amps (A) 17.2
Plug Configuration NEMA L15-30P
Dimensions (W x H x D) 45 (w/casters 50.25) x 27.5 x 35 (w/2" kick plate)
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 3 ton 36,050 Btu/h
Voltage/Amps (@60Hz) 460 3-Phase
Amps (A) 8.7
Plug Configuration NEMA L16-20P
Dimensions (W x H x D) 45 (w/casters 50.25) x 27.5 x 35 (w/2" kick plate)
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 5 ton 60,100 Btu/h
Voltage/Amps (@60Hz) 208-230 1-Phase
Amps (A) 32
Plug Configuration NEMA 6-50P
Dimensions (W x H x D) 45.5 (w/casters 51.75) x 27.5 x 39.5 (w/2" kick plate)
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 5 ton 60,100 Btu/h
Voltage/Amps (@60Hz) 208-230 3-Phase
Amps (A) 20.4
Plug Configuration NEMA L15-30P
Dimensions (W x H x D) 45.5 (w/casters 51.75) x 27.5 x 39.5 (w/2" kick plate)
Ambient Operating Range (w/opt. hot-gas bypass) 65°-105°F
Cooling Capacity 5 ton 60,100 Btu/h
Voltage/Amps (@60Hz) 460 3-Phase
Amps (A) 14.8
Plug Configuration NEMA L16-20P
Dimensions (W x H x D) 45.5 (w/casters 51.75) x 27.5 x 39.5 (w/2" kick plate)
